Position: Productos > Cámaras IP > TPAA Series IR Mini PTZ IP Cameras > CY-TPAA2015M IR 2.0M Pixels HD Wireless Wifi Intdoor Robot IP Camera

15M IR 2.0M Pixels HD Wireless Wifi Intdoor Robot IP Camera

  • 15M IR 2.0M Pixels HD Wireless Wifi Intdoor Robot IP Camera
  • 15M IR 2.0M Pixels HD Wireless Wifi Intdoor Robot IP Camera

  • 15M IR 2.0M Pixels HD Wireless Wifi Intdoor Robot IP Camera
Model: CY-TPAA20
Name: 15M IR 2.0M Pixels HD Wireless Wifi Intdoor Robot IP Camera
System: Embedded Linux
Sensor: 1/3" GC2023 CMOS
ChipSet: HI3516C
Compression: H.264
Resolution: 2.0M Pixel HD
Pixels: 1920(H)*1280(V)(NTSC)/1920(H)*1280(V)(PAL)
Video: H.264 code;
frame rate 1-30fps;
double stream,0.4M-2Mpbs for choosing;
subcode stream:D1(704*576@30fps);
main stream:1080P(1920*1080@30fps);
video output:1ch 1080P(1920*1080)2.0M HD network digital video output;
lowest Illuminance: 0.01Lux(F1.2,AGC On)/ 0Lux (IR On);
Audio: G.711A coding standard,the synchronization of audio and video;
1ch input,electrical level 2Vp-p,impedance 1kΩ,support audio pickup input;
Alarm: -
IR: 11pcs Ф5 IR LED,IR night vision distance 10-15m;
Lens: default 3.6MM Fixed Focus Lens;
PTZ Function: Pan:90 deg;
Tilt:270 deg;
building Decoder,can control by remote,no need setup;
WaterProof: -
Record Model: Manual,Schedule,Motion Detection,Network remote recording;
Backup: Network Backup;
Store: Network storage; Local TF card storage(optional,Maximum support 64G);
Note: If not mentioned,the price not including the storage.
 Language: Ingles, chino simplificado, chino tradicional, italiano, español, japonés, ruso, francés, alemán, portugués, polaco, turco, rumano, húngaro, finlandés, danés, Persa, griego, tailandés, vietnamita, Portugues (Brasil), hebreo, árabe, sueco, Indonesio, checo, Ucrania, Eslovaquia, Holanda;
Remoter: IE, Chrome, Firefox, Safari and other web browser WEB monitoring;
IPhone, Android and other mobile client monitoring;
CMS, central platform management software and other PC client monitoring;
Network: PPPOE dial service;
NTP network time synchronization;
Email send alarm picture service;
IP black and white list;
DDNS dynamic domain name service;
FTP video file upload;
ARSP free domain access function;
Alarm Center;
3G wireless dialing;
UPNP automatic port mapping function;
WIFI wireless connection;
RTSP real time streaming protocol;
P2P cloud monitoring service;
Alarm information pushed to the phone;
Settable: Exposure mode: automatic / manual (1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000,);
Exposure time: 0.256000-65.536000 adjustable;
Day / night mode: automatic / color / BW;
BLC: on / off;
Auto aperture: on / off;
Scene mode: Auto / indoor / outdoor;
WDR: on / off;
Defogging: on / off;
Auto gain: on / off;
Electronic slow shutter: no / weak / medium / strong;
IR-CUT: IR synchronous switch/ automatic switching;
Day / night de-noising level: 0-5 adjustable;
  Mirror image;
  Image flip;
  Fluorescent lamp anti flash;
  IR lens reverse order;
HD stream resolution: 1080P/3M/4M;
Stream value: 1145-4686KB/S adjustable;
Standard stream: D1/CIF;
Stream value: 190-1024KB/S adjustable;
Other Function: Support Stand ONVIF protocol;
Digital WDR,Support 3D de-noising;
POE Function and Build-in TF Card(Maximum support 32G) are optional;
Mechanical IR-CUT, automatic switching day and night;
Support USB interface extension WIFI/3G function;
7*24 hours 65℃ high temperature test stable and reliable;
Embedded RTOS design, dual core 32 bit DSP (Hi3516D), pure hard compression, watchdog;
Power, network, POE comprehensive meet lightning protection standard, in line with the national standard GB/T17626.5 , the international standard IEC61000-4-5;
Support WEB configuration, support OSD, support real-time video transmission, support motion detection and alarm linkage, support front-end storage playback / download, mobile detection and alarm center to remind and pictures pop-up linkage, support MJPEG capture, support the application of unified client remote monitoring software, the MYEYE platform and  provides SDK development package;
I/O Interface: 1 PCS TF Card slot;
1 PCS DC5V power input interface;
1 PCS 10/100M RJ45 adaptive Ethernet interface;
Power: DC12V,2A
Work Temperature: -15℃~50℃ºC
Work Humidity: <=95%RH
Dimensions: 127*107*99 CM
Carton Size: 145*145*150 CM
Net Weight: 0.3 KG
Rough Weight: 0.66 KG
Total Wweight: 0.7 KG
